ICON 2005-07 Ford F250/F350, 7" Lift, Stage 3 Suspension System
Suspension Lift Kit
2005-2007 FORD F-250/F-350 7" LIFT STAGE 3 SUSPENSION SYSTEM
ICONs 7†Suspension System for the 2005-2007 Ford Super Dutys offer unparalleled performance and ride quality while giving the vehicle clearance for 38†tall tires. This system comes complete with ICON 2.5 Aluminum Series Shocks, Dual-Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, and ICON's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by ICONs Limited Lifetime Warranty.
- 75% increase in wheel travel
- Less body roll than stock truck
- 7” more travel from ride height to front bump stops
- State of the art dual-rate coil spring
- Lifetime guarantee that coil springs won’t sag
- Clears 38" Tall Tires
- No change in towing capacity
- No driveshaft modifications needed
- 100% Bolt-on system - No drilling, cutting, or welding necessary
Application Notes
OEM Wheels & Tires Fitment: Yes Recommended Aftermarket Wheels: ICON Alloys | 17x8.5" w/ 5.00” Backspace / 6mm Offset Recommended Aftermarket Wheels: ICON Alloys | 18x9" w/ 5.25” Backspace / 6mm Offset Recommended Aftermarket Wheels: ICON Alloys | 20x9" w/ 5.25” Backspace / 6mm Offset Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.) APPLICATION NOTE #6: SPRINGS ARE RATED FOR DIESEL ENGINES ONLY APPLICATION NOTE #21: NOT APPLICABLE ON VEHICLES EQUIPPED WITH A MANUAL TRANSMISSION APPLICATION NOTE #28: PINCH WELD ON ‘05-’10 SUPERDUTY RADIUS ARMS MAY COME IN CONTACT WITH RADIUS ARM DROP BRACKET HARDWARE APPLICATION NOTE #29: 7” SYSTEMS USING A 4-LINK IN PLACE OF THE FACTORY RADIUS ARMS DO NOT REQUIRE THE USE OF ALIGNMENT CAMS. CASTER CAN BE ADJUSTED BY THE LOWER LINK ARMS APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE APPLICATION NOTE #57: RETAINS FACTORY BLOCK FOR TRUCK TO SIT LEVEL WITH FRONT OF TRUCK Ships in multiple boxes
Shipping Information
- Item Requires Shipping
- 425.0 lbs.
- W48.0000” x H10.0000” x L48.0000”
- Free Shipping via UPS Ground in the lower Contiguous 48 United States Only, Orders Over $200 USD
