FOX Offroad Shocks
Additional Images

FOX FACTORY RACE SERIES 3.0 EXTERNAL BYPASS SHOCK (PAIR) - 10-ON Ford Raptor Rear External Bypass 3.0 Series P/B 11.5 0-1 Lift

Suspension Shock Absorber Kit

883-02-047

Application specific valving to maximize performance.

Developed from our off-road race shocks, FOX Factory Race Series combines race-proven technology with new, cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV.

  • Performance Tuned For Vehicle Specific Application
  • Durable Zinc Plated Seamless Alloy Body
  • External Reservoir System Dissipates Heat Fast
  • Black Anodized CNC Machined Aluminum Components

Applications:

Ford F-150: 2010 - 2014

Pricing: $3,199.95

Qty:
Free Shipping via UPS Ground in the lower Contiguous 48 United States Only

Compatibility

Accommodates: 0" to 1" of Lift

2010-2014 Ford F150 Raptor

Specs

Accommodates: 0" to 1" of Lift
Position: Rear
Extended Length: 29.41"
Collapsed Length: 17.92"
Travel: 11.48"
Top Mount: Eyelet
Bottom Mount: Eyelet
Reservoir: Piggyback
*Picture is for illustration only

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 90.0 lbs.
  • W17.5000” x H8.5000” x L31.5000”
  • Free Shipping via UPS Ground in the lower Contiguous 48 United States Only

Documents
